Description
Explore the 20FT X 8FT Anti Vandal Office Canteen – Durable Modular Workspace at 175 Container Partner for workspace and modular building projects. Compare the layout, access points, insulation, and listed utilities with your space and site requirements.
The specification and configuration details below help you assess this model. Confirm the actual unit, included equipment, delivery access, and any documentation needed for your intended use before ordering. Optional features are separate from standard inclusions.
Technical Specifications
| Specification | Listed Detail |
|---|---|
| External Dimensions (L x W x H) | Approx. 20 ft x 8 ft x 8.5 ft (6.05m x 2.44m x 2.59m) |
| Internal Area | Approx. 140-150 sq. ft (13-14 m²) |
| Structural Material | Corten Steel (weathering steel) with a protective industrial coating |
| Wall & Ceiling Insulation | 30-50 mm Polyurethane (PUR) foam or Mineral Wool |
| Flooring | 2mm Vinyl or composite board over marine-grade plywood |
| Electrical Supply | External 32A 400V three-phase connection point with integrated consumer unit |
| Internal Fit-Out | Pre-wired LED lighting, double power sockets (220V), light switches |
| Window/Door Fittings | Heavy-duty, lockable steel doors and windows with anti-vandal glazing options |
| Weight | Approx. 2,500 – 3,000 kg (depending on fit-out) |
Applications and Compatibility
- Construction Sites: As a site office or secure canteen for personnel.
- Industrial Facilities: As a control room, security hut, or break room.
- Events and Festivals: As a staff base, first-aid point, or secure storage and service area for catering vendors .
- Commercial Properties: As a satellite office, concession stand, or small takeaway food outlet .
Listed Inclusions
- 1 x 20 ft Modified Shipping Container structure with anti-vandal specifications.
- Pre-fitted thermal insulation to walls, ceiling, and floor.
- Installed electrical system: Internal lighting, power sockets, and external hook-up point.
- Commercial-grade flooring.
- External and internal steel doors with heavy-duty locking systems.
- Fixed windows (as per configuration).
Additional Listed Features
- Anti-Vandal Specification: Constructed with heavy-duty steel cladding and fitted with secure lockboxes and tamper-resistant fixtures to protect the interior and its contents .
- Fully Insulated Interior: The walls, ceiling, and floor are lined with insulation (such as polyurethane foam or EPS sandwich panels) to regulate internal temperature and reduce external noise, creating a comfortable environment .
- Integrated Electrical System: Pre-wired with a concealed electrical installation, including internal lighting, switched sockets, and an external connection point for a mains power supply .
- Commercial Flooring: Fitted with durable, easy-to-clean flooring. In areas intended for food preparation or consumption, this surface is selected for its resistance to stains and compliance with food safety standards .
- Multi-Room Potential: The internal space is designed to accommodate distinct areas, allowing for a segregated server, kitchenette, or storage zone within the single unit .
