Explore the 40 ft High Cube Refrigerated Reefer Container – Carrier PrimeLINE Unit at 175 Container Partner for temperature-controlled storage. Compare the cooling equipment, insulation, power supply, and stated operating range with the needs of your goods and installation site.
The specification and configuration details below help you assess this model. Confirm the actual unit, included equipment, delivery access, and any documentation needed for your intended use before ordering. Optional features are separate from standard inclusions.
Technical Specifications
| Specification | Listed Detail |
|---|---|
| External Dimensions | | |
| Length | 40 ft | 12,192 mm |
| Width | 8 ft | 2,438 mm |
| Height | 9 ft 6 in | 2,896 mm |
| Internal Dimensions | | |
| Length | Approx. 38 ft | Approx. 11,588 mm |
| Width | Approx. 7 ft 6 in | Approx. 2,284 mm |
| Height | Approx. 8 ft 4 in | Approx. 2,545 mm |
| Door Opening | | |
| Width | Approx. 7 ft 6 in | Approx. 2,290 mm |
| Height | Approx. 8 ft 6 in | Approx. 2,596 mm |
| Weights | | |
| Maximum Gross Weight | 77,160 lbs | 35,000 kg |
| Tare Weight (with machinery) | Approx. 9,700 lbs | Approx. 4,400 kg |
| Maximum Payload | Approx. 67,460 lbs | Approx. 30,520 kg |
| Internal Capacity | Approx. 2,380 ft³ | Approx. 67.4 m³ |
| ISO Code | 45R1 | |
| | |
Applications and Compatibility
- The long-distance transport of perishable food items such as fruits, vegetables, meat, and dairy products.
- Storage of temperature-sensitive non-food items, including certain pharmaceuticals, flowers, and agricultural products .
- On-site temperature-controlled storage solutions for warehouses, distribution centers, or event logistics .
- Use as a temporary or permanent cold room for facilities requiring additional refrigerated space.
Additional Listed Features
- Carrier Primeline Refrigeration Unit : Equipped with a Carrier Primeline system, known for its high performance and energy-efficient operation. The unit utilizes an electronic expansion valve and advanced control software to manage temperature tolerances .
- High Cube Configuration : The 9’6″ external height provides a higher internal cubic capacity, which is uses: stacking taller loads or maximizing storage volume within a fixed footprint .
- Robust T-Floor Construction : Features a durable aluminum T-floor (often grade 6082 T6), designed to facilitate air circulation from the refrigeration unit throughout the cargo area and withstand heavy loading .
- Durable Exterior and Interior : The exterior is material: corrosion-resistant materials such as Corten steel, while the interior lining is often made from food-grade stainless steel or aluminum to ensure hygiene and durability .
- Low Air Leakage : Engineered with efficient door seals and sill designs to minimize air exchange, thereby reducing energy consumption and maintaining stable internal conditions .
