Description
Explore the Container Office – Durable Modular Workspace Solution at 175 Container Partner for workspace and modular building projects. Compare the layout, access points, insulation, and listed utilities with your space and site requirements.
The specification and configuration details below help you assess this model. Confirm the actual unit, included equipment, delivery access, and any documentation needed for your intended use before ordering. Optional features are separate from standard inclusions.
Technical Specifications
| Specification | Listed Detail |
|---|---|
| External Dimensions (LxWxH) | 20 ft: 20′ x 8′ x 8’6″ (6.06m x 2.44m x 2.59m) 40 ft: 40′ x 8′ x 8’6″ (12.2m x 2.44m x 2.59m) |
| Internal Dimensions (LxWxH) | 20 ft: Approx. 19’4″ x 7’8″ x 7’10” (5.89m x 2.35m x 2.39m) |
| Material | Corrugated Corten Steel (A606/A588) |
| Frame Material | Structural Carbon Steel |
| Interior Wall Lining | 8mm MDF or Pre-finished Steel Laminate |
| Flooring | 28mm Marine-Grade Plywood |
| Insulation | Mineral Wool / Fiberglass |
| Door Type | Single Steel Personnel Door with Locking Handle |
| Windows | Optional – Can be installed upon request |
| ISO Corner Castings | Yes, compliant with ISO 1161:2016 |
| Empty Weight (Tare) | 20 ft: Approx. 2,200 kg (4,850 lbs) |
Applications and Compatibility
- Construction Site Offices: A secure and weatherproof on-site location for project managers and site meetings .
- Security Checkpoints: A durable and elevated position for security personnel at gates or entry points.
- Event Management: A functional headquarters for event coordination, ticketing, or first aid at festivals and sports events .
- Industrial & Mining Camps: Provides essential administrative or meeting space in remote operational locations .
- Retail & Agriculture: Can serve as a temporary sales kiosk, a farm office, or a storage shed with a workspace.
Listed Inclusions
- 1 x Container Office unit as specified (walls, floor, roof, frame).
- 1 x Steel personnel door with locking mechanism.
- Pre-fitted electrical conduit and socket boxes (internal fittings not installed).
- Standard ISO corner castings for lifting and stacking.
Additional Listed Features
- Robust Steel Construction: Built with a heavy-duty Corten steel frame and corrugated wall panels for structural integrity and long-term durability .
- Modular & Portable Design: for easy transportation and relocation. Units can be stacked or combined to create larger office complexes .
- Fully Insulated: Equipped with high-density mineral wool insulation in the walls (60mm), roof (100mm), and floor (100mm) to maintain a stable internal temperature .
- Weather-Resistant: Engineered with weather-proof materials and sealed to be leak-proof, protecting the interior from the elements .
- Pre-Galvanized for Corrosion Resistance: The steel components are treated to resist rust and corrosion, supporting longevity in various outdoor conditions.
- Lockable Entry: Includes a secure, lockable steel personnel door for controlled access and security .
